2015 Casadei Flexa 27 Edgebander

Panel height: 0.3 – 2.36”

Coil edge thickness: .12”

Strip edge thickness: .015 – .24”

Max Overhang Total Top and Bottom: 0.16”

Min panel width (min length of 8 ¼”: 3.54”

Min panel length (min width of 3-15/16″): 5.5”

Feed Speed: 33 f/min

Glue Tank GP-200 Power: 2.4 kW

Glue Capacity: 3.3 lbs

End Trimming Unit IK/200 (each): .3 HP

Cutting Speed: 12,000 RPM

Blade Tilt: 0-15 deg.

Top and Bottom Trimming TT/K Motor (each): .4 HP

Cutting Speed: 12,000 RPM

Shipping Footprint: 13′ x 4′ x 5′

Weight: 2500 lbs

Equipped With:

– Pre-Milling Unit

– Glue Applicator and Pressure Rollers

– Edgebanding Trimming Guillotine

– End Trim With 2 Tiltable Motors 0-15 deg.

– Top and Bottom Trimming via 2 Motors

– Profile/ Radius Scrape

– Glue Scraping

– Buffing
