2023 Laguna Smartshop II Pro CNC Router

Gantry Clearance: 12″

Z Axis Travel: 13″

Table Size: 4’x8′

Working Area: 49″x97″

Rapid Speed: 1,800 IPM

Cutting Speed: 1,000 IPM

Spindle HP: 12HP

Spindle Speed: 6,000 – 24,000 RPM

Cutting Time: 50 Hours

Electrical: 208-230V/ 3PH

Equipped With:

12 HP HSD Spindle

8 Position ISO 30 ATC

Yaskawa AC Servos Drive Motors

6 Zone Vacuum Table

Planetary Gear Box Drive System

Tooling Kit

Helical Rack & Pinion X/Y Axis

Ball Screw Z Axis

10 HP Stock Regenerative Blower Vacuum Pump

Syntec Industrial Control System

Controller: B+R PP65 Stepper Package

Footprint: 78″x127″

Approx. Shipping Weight: 3,500 Lbs
