2016 Holzma HPP200 Panel Saw
Sold
Specifications
Manufacturer | Holzma |
Model | HPP200 Panel Saw |
Year | 2016 |
Stock Number | 009892 |
Description
This machine will be available around December 1, 2022.
- Model No HPP 250
- Year of manufacture 2016
- Cutting length 3800 mm
- Pusher stroke 3700 mm
- Saw blade projection 80 mm
- Saw Diameter 350 mm
- Main Motor 9.2 kW
- Scoring Unit yes D=200mm
- Scoring Motor 1.1 kW
- Single sided side-aligner
- Number of grippers
- Continuously variable feed
- Graphical cutting pattern
- Air pressure required 6 bar
- Total air requirements 150 NL/min
- V min. velocity at ducts approx. 25 m/s
- Negative pressure min. 1200 Pa
- Suction capacity 3800 m?/h
- Duct for channel connection 1 pce 160 mm
- Duct for pressure beam connection 1 pce 140 mm
